Product Description
|
Model H5-3C, a new design of vertical drilling machine have been developed, according to customers' requirement. In comparision with the old model H5-3, the performance of H5-3C is much more perfect. This machine is designed for drilling, counterboring, spotfacing, tapping etc. in small or middle sized components with max. diameter 25mm. It is inteneded for single piece, small batch or batch production in machining or repair shops. The Siemens motor control switch is used in products for export
|
| |
| Drilling H5-32 Specification |
| Max. diameter to be drilled |
32mm |
| Max. travel of spindle |
150mm |
| Distance from axis of spindle to generating line of column |
300 mm |
| Max. distance from spindle nose to working surface |
800 mm |
| Max. distance from spindle nose to working surface of baseplate |
1225 mm |
| Max. tracel of drill head |
270 mm |
| Max. travel of table |
550 mm |
| Spindle taper |
Morse No.4 |
| Number of spindle speeds |
12 steps |
| Range of speeds |
78 - 105 - 160 - 235 -315 - 400 - 480 - 555 - 840 -1230 - 1650 - 2500r.p.m. |
| Effective working area of round table |
| JDO T-100L 3-speed 3-phase A.C. motor |
Power |
1 - 1.3 - 1.7 kW |
| Voltage (to be stipulated time of ordering) |
220. 380. 420 |
| Speed |
705 - 950 - 1440 r.p,m |
| Overall dimension (L x W x H) |
(780 x 505 x 1770)mm³ |
| Weight of the machine |
390 kg |
|
| |
